POP UP

CEILING RECESSED

Pop Up is one of the smallest recessed spotlights in the world. It combines its small format with formal minimalism to achieve the perfect luminaire for projects that require the least possible space invasion. Pop Up is able to render a luminous flux that allows it to undertake accent lighting functions from the ceiling. It can be moved in practically all the degrees of freedom, as it rotates 355° and can tilt at 90° (unlike the majority of other recessables on the market). It can be easily and smoothly moved by hand.

Awards

  • European Product Design Winner 2018

    European Product Design Winner 2018

POP UP

  • Mounting accessories

    Remote Box

  • Luminous flux

    461 lm / 483 lm / 517 lm

  • Lighting efficiency

    86% / 89% / 92%

  • Power

    4.5 W

  • Dimming

    0-10V

  • Colour temperature

    2700K / 3000K / 4000K

  • Chromatic stability

    MacAdam Step 2

  • Light beam angle

    20 / 30 / 56

EPD Instructions BIM
Luminous flux
    • Power
    • Colour temperature
    • Lighting efficiency
    • Mounting Accessory
      IC Rated
        Input Voltage
          CRI
            Light beam angle
              Dimming
                Cord length
                  Colour

                    • Model

                      Ref.

                      Mounting Accessory / Driver

                      Colour

                      Lum. flux

                      Power

                      Temp.

                      CRI

                      Beam angle

                      Efficiency

                      IC Rated

                    • POP UP UL 20º 2700K NT
                      Reference:

                      U2782110NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      461 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      2700K

                      CRI:

                      CRI>90

                      Light beam angle:

                      20

                      Lighting efficiency:

                      92%

                      IC Rated:

                      Yes

                    • POP UP UL 20º 2700K WT
                      Reference:

                      U2782110WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      461 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      2700K

                      CRI:

                      CRI>90

                      Light beam angle:

                      20

                      Lighting efficiency:

                      92%

                      IC Rated:

                      Yes

                    • POP UP UL 20º 3000K NT
                      Reference:

                      U2782111NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      483 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      3000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      20

                      Lighting efficiency:

                      92%

                      IC Rated:

                      Yes

                    • POP UP UL 20º 3000K WT
                      Reference:

                      U2782111WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      483 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      3000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      20

                      Lighting efficiency:

                      92%

                      IC Rated:

                      Yes

                    • POP UP UL 20º 4000K NT
                      Reference:

                      U2782112NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      517 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      4000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      20

                      Lighting efficiency:

                      92%

                      IC Rated:

                      Yes

                    • POP UP UL 20º 4000K WT
                      Reference:

                      U2782112WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      517 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      4000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      20

                      Lighting efficiency:

                      92%

                      IC Rated:

                      Yes

                    • POP UP UL 30º 2700K NT
                      Reference:

                      U2782120NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      461 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      2700K

                      CRI:

                      CRI>90

                      Light beam angle:

                      30

                      Lighting efficiency:

                      89%

                      IC Rated:

                      Yes

                    • POP UP UL 30º 2700K WT
                      Reference:

                      U2782120WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      461 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      2700K

                      CRI:

                      CRI>90

                      Light beam angle:

                      30

                      Lighting efficiency:

                      89%

                      IC Rated:

                      Yes

                    • POP UP UL 30º 3000K NT
                      Reference:

                      U2782121NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      483 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      3000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      30

                      Lighting efficiency:

                      89%

                      IC Rated:

                      Yes

                    • POP UP UL 30º 3000K WT
                      Reference:

                      U2782121WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      483 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      3000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      30

                      Lighting efficiency:

                      89%

                      IC Rated:

                      Yes

                    • POP UP UL 30º 4000K NT
                      Reference:

                      U2782122NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      517 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      4000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      30

                      Lighting efficiency:

                      89%

                      IC Rated:

                      Yes

                    • POP UP UL 30º 4000K WT
                      Reference:

                      U2782122WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      517 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      4000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      30

                      Lighting efficiency:

                      89%

                      IC Rated:

                      Yes

                    • POP UP UL 56º 2700K NT
                      Reference:

                      U2782130NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      461 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      2700K

                      CRI:

                      CRI>90

                      Light beam angle:

                      56

                      Lighting efficiency:

                      86%

                      IC Rated:

                      Yes

                    • POP UP UL 56º 2700K WT
                      Reference:

                      U2782130WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      461 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      2700K

                      CRI:

                      CRI>90

                      Light beam angle:

                      56

                      Lighting efficiency:

                      86%

                      IC Rated:

                      Yes

                    • POP UP UL 56º 3000K NT
                      Reference:

                      U2782131NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      483 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      3000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      56

                      Lighting efficiency:

                      86%

                      IC Rated:

                      Yes

                    • POP UP UL 56º 3000K WT
                      Reference:

                      U2782131WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      483 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      3000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      56

                      Lighting efficiency:

                      86%

                      IC Rated:

                      Yes

                    • POP UP UL 56º 4000K NT
                      Reference:

                      U2782132NT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured black

                      Luminous flux:

                      517 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      4000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      56

                      Lighting efficiency:

                      86%

                      IC Rated:

                      Yes

                    • POP UP UL 56º 4000K WT
                      Reference:

                      U2782132WT

                      Mounting Accessory / Driver:

                      Remote Box
                      REMOTE BOX 4-23W 500mA
                      U1000035 · 1 to 5 Luminaires
                      (Mandatory / not included)

                      Colour:

                      Textured white

                      Luminous flux:

                      517 lm

                      Power:

                      4.5 W

                      Colour temperature:

                      4000K

                      CRI:

                      CRI>90

                      Light beam angle:

                      56

                      Lighting efficiency:

                      86%

                      IC Rated:

                      Yes

                    Accessories

                    BEAM MIXER DIFFUSER
                    ANTI-GLARE HONEYCOMB LOUVER
                    OPTIONAL MOUNTING ACCESSORY
